Excellent garden equipment for you and agriculture. Farm wheelbarrows are made of steel. And a solid frame from the pipe. This makes the unicycle very durable and can be used for many years. The body is made of galvanized steel.
Tank material: galvanized steel
Dimensions Length/width: 1390×680 mm
Wheel diameter: 4.80/4.00-8 Pneumatic tire.
Groove thickness: 0.8 mm
Load capacity: 150 kg
Weight 11 kg
Body capacity: 90 liters
Color: Orange, stainless steel
The wheelbarrow WB 5009-100 has a slot capacity of 100 liters and is used for maintenance and construction work. Loose building materials can be used on top: sand, gravel, brick, stone, or tools. The load capacity is 150 kg.
Design
The frame is composed of hollow tubes and consists of two composite half-frames. These half-frames are curved, so they serve as both a bearing platform for the body and a support platform for the legs. To protect the frames of the construction unicycles from corrosion, the pipes are coated with powder enamel.
The 100-liter tray is made of galvanized steel, 0.8 mm thick. The sides are rounded for increased rigidity and impact protection. 4.00–8 Wheels with a diameter of 395 mm are equipped with sealed bearings.
When assembled on a half frame, an auxiliary support arc is installed in front of the wheel, which can be used as a unicycle dump truck when unloading bulk goods.
Characteristic category
Wheelbarrow Reinforced Garden wheelbarrow construction wheelbarrow
| Item No | WB5009 |
|---|---|
| Load cap./volume (kg/l.) | 150 / 100 |
| Frame Dimensions LxWxH (mm) | 1390 x 680 x 580 |
| Handle Tube (mm) | 32 x 1.50 or Customized. |
| Tray Dimension LxW (mm) | 880 x 600 x 280 |
| Tray Thickness (mm) | 1.00 or Customized |
| Tray Material | Steel or Poly |
| Wheel | 4.80/4.00-8 Pneumatic Wheel |
| Approx.Weight (Kg) | 11.50 |
| Delivered | Unassembled in bulk. |
